    EN10204 3.1 Carbon Steel Stainless Steel Fitting SGP JIS B2311 Elbow Tee Reducer Cap

    Ask Lasest Price
    Brand Name : XF/XINFENG
    Model Number : 1/2"-72"
    Certification : ISO9001 , PED AND AD2000 W0 EN10204 3.1
    Price : 1USD
    Payment Terms : L/C, D/A, D/P, T/T
    Supply Ability : 2000TONS ONE MONTH
    Delivery Time : 30DAYS
    • Product Details
    • Company Profile

    EN10204 3.1 Carbon Steel Stainless Steel Fitting SGP JIS B2311 Elbow Tee Reducer Cap

    STEEL FITTING SGP JIS B2311 ELBOW TEE REDUCER AND CAP

    STEEL FITTING SGP JIS B2311 ELBOW TEE REDUCER AND CAP CARBON STEEL STAINLESS STEEL

    Standard JIS B2311
    Fitting type

    ELBOW LR/SR, 45DEG/90DEG/180DEG; Tee Equal/reducing;

    Reducer concentric/Eccentric; Cap ; Cross

    Thickness SGP
    Material A234 WPB ,SS400 SS304/304L SS316/316L
    Size range 1/2" to 24" seamless type; 4" to 72" welded type
    Coating Oil , Cold Galvanized and Hot Galvanized

    EN10204 3.1 Carbon Steel Stainless Steel Fitting SGP JIS B2311 Elbow Tee Reducer Cap

    EN10204 3.1 Carbon Steel Stainless Steel Fitting SGP JIS B2311 Elbow Tee Reducer Cap


    Dimensions of SGP Elbows in JIS B2311/B2312.

    Dimensions of JIS B2311/ B2312 SGP standard Elbows.

    EN10204 3.1 Carbon Steel Stainless Steel Fitting SGP JIS B2311 Elbow Tee Reducer Cap

    JIS-B2311-B2312-SGP-ELBOW-BEND-DRAWING

    45° and 90° SGP elbows dimensions in mm

    Nominal OD Center to End 90˚Weight 45 °Weight
    (NPS) 90˚(F) 45˚(H) KG/PC KG/PC
    A B D Long Shot Long Long Short LONG
    15 ½ 21.7 38.1 - 15.8 0.08 0.05 0.04
    20 ¾ 27.2 38.1 - 15.8 0.1 0.07 0.05
    25 1 34 38.1 25.4 15.8 0.15 0.1 0.08
    32 42.7 47.6 31.8 19.7 0.26 0.17 0.13
    40 48.6 57.2 38.1 23.7 0.35 0.24 0.18
    50 2 60.5 76.2 50.8 31.6 0.64 0.43 0.32
    65 76.3 95.3 63.5 39.5 1.12 0.75 0.56
    80 3 89.1 114.3 76.2 47.3 1.58 1.05 0.79
    90 101.6 133.4 88.9 55.3 2.17 1.45 1.09
    100 4 114.3 152.4 101.6 63.1 2.91 1.94 1.46
    125 5 139.8 190.5 127 78.9 4.49 2.99 2.25
    150 6 165.2 228.6 152.4 94.7 7.09 4.73 3.55
    200 8 216.3 304.8 203.2 126.3 14.4 9.61 7.2
    250 10 267.4 381 254 157.8 25.4 16.9 12.7
    300 12 318.5 457.2 304.8 189.4 38.1 25.4 19.05
    350 14 355.6 533.4 355.6 220.9 56.7 37.8 28.35
    400 16 406.4 609.6 406.4 252.5 74.3 49.5 37.15
    450 18 457.2 685.8 457.2 284.1 94.2 62.8 47.1
    500 20 508 762 508 315.6 116 77.7 58
    550 22 558.8 838.2 558.8 347.2 141 94.1 70.5
    600 24 609.6 914.4 609.6 378.7 168 112 84
    650 26 660.4 990.6 660.4 410.3 198 132 99
    700 28 711.2 1066.8 711.2 441.9 230 154 115
    750 30 762 1143 762 473.4 264 176 132
    800 32 812.8 1219.2 812.8 505 301 201 150.5
    850 34 863.6 1295.4 863.6 536.6 340 227 170
    900 36 914.4 1371.6 914.4 568.1 380 253 190
    950 38 965.2 1447.8 965.2 599.7 425 283 212.5
    1000 40 1016 1524 1016 631.2 471 314 235.5
    1050 42 1066.8 1600.2 1066.8 662.8 518 346 259
    1100 44 1117.6 1676.4 1117.6 694.4 570 380 285
    1150 46 1168.4 1752.6 1168.4 725.9 623 415 311.5
    1200 48 1219.2 1828.8 1219.2 757.5 677 452 338.5

    180° SGP elbows Dimensions in mm

    Nominal OD C to C End to End 180˚Weight
    (NPS) 180˚ (P) 180˚(K) KG/PC
    A B D Long Shot Long Shot Long Short
    15 ½ 21.7 76.2 - 49 - 0.16 0.1
    20 ¾ 27.2 76.2 - 51.7 - 0.2 0.14
    25 1 34 76.2 50.8 55.1 42.4 0.3 0.2
    32 42.7 95.2 63.6 69 53.2 0.52 0.34
    40 48.6 114.4 76.2 81.5 62.4 0.7 0.48
    50 2 60.5 152.4 101.6 106.5 81.1 1.28 0.86
    65 76.3 190.6 127 133.5 101.7 2.24 1.5
    80 3 89.1 228.6 152.4 158.9 120.8 3.16 2.1
    90 101.6 266.8 177.8 184.2 139.7 4.34 2.9
    100 4 114.3 304.8 203.2 209.6 158.8 5.82 3.88
    125 5 139.8 381 254 260.4 196.9 8.98 5.98
    150 6 165.2 457.2 304.8 311.2 235 14.18 9.46
    200 8 216.3 609.6 406.4 413 311.4 28.8 19.22
    250 10 267.4 762 508 514.7 387.7 50.8 33.8
    300 12 318.5 914.4 609.6 616.5 464.1 76.2 50.8
    350 14 355.6 1066.8 711.2 711.2 533.4 113.4 75.6
    400 16 406.4 1219.2 812.8 812.8 609.6 148.6 99
    450 18 457.2 - - - - 188.4 125.6
    500 20 508 - - - - 232 155.4
    550 22 558.8 - - - - 282 188.2
    600 24 609.6 - - - - 336 224
    650 26 660.4 - - - - 396 264
    700 28 711.2 - - - - 460 308
    750 30 762 - - - - 528 352
    800 32 812.8 - - - - 602 402
    850 34 863.6 - - - - 680 454
    900 36 914.4 - - - - 760 506
    950 38 965.2 - - - - 850 566
    1000 40 1016 - - - - 942 628
    1050 42 1066.8 - - - - 1036 692
    1100 44 1117.6 - - - - 1140 760
    1150 46 1168.4 - - - - 1246 830
    1200 48 1219.2 - - - - 1354 904

    EN10204 3.1 Carbon Steel Stainless Steel Fitting SGP JIS B2311 Elbow Tee Reducer Cap
